zaj-MySQL-MCP

A Model Context Protocol (MCP) server implementation that provides database interaction and business intelligence capabilities through MySQL. This server enables running SQL queries, analyzing business data, and automatically generating business insight memos.

Features

Execute SQL queries against a MySQL database
Create and manage database tables
Analyze database schema
Generate and store business insights
Access a continuously updated business insights memo

Tools

Query Tools

read_query: Execute SELECT queries to read data from the database
- Input: query (string) - The SELECT SQL query to execute
- Returns: Query results as array of objects
write_query: Execute INSERT, UPDATE, or DELETE queries
- Input: query (string) - The SQL modification query
- Returns: { affected_rows: number }
create_table: Create new tables in the database
- Input: query (string) - CREATE TABLE SQL statement
- Returns: Confirmation of table creation

Schema Tools

list_tables: Get a list of all tables in the database
- No input required
- Returns: Array of table names
describe_table: View schema information for a specific table
- Input: table_name (string) - Name of table to describe
- Returns: Array of column definitions with names and types

Analysis Tools

append_insight: Add new business insights to the memo resource
- Input: insight (string) - Business insight discovered from data analysis
- Returns: Confirmation of insight addition
- Triggers update of memo://insights resource

Resources

The server exposes a single resource:

memo://insights: A continuously updated business insights memo that aggregates discovered insights during analysis
- Auto-updates as new insights are discovered via the append-insight tool

Implementation Details

This MCP server implements the Model Context Protocol directly, without relying on external SDK dependencies. It uses:

mysql2: For MySQL database connectivity
yargs: For command-line argument parsing
readline: For handling stdin/stdout communication

The server follows the JSON-RPC 2.0 protocol for communication with Claude, handling requests for tool listings, resource listings, and tool execution.

Configuration

The MySQL MCP server uses environment variables for configuration. Create a .env file in the root directory with the following variables:

# Database Connection
DB_CONNECTION=mysql

# Database Host
DB_HOST=localhost

# Database Port
DB_PORT=3306

# Database Username (required)
DB_USER=your_mysql_username

# Database Password (required)
DB_PASSWORD=your_mysql_password

# Database Name (required)
DB_NAME=your_database_name

A .env.example file is provided as a template. Copy it to .env and update the values:

cp .env.example .env
# Then edit .env with your database credentials

Usage with Claude Desktop

Add the server to your cline_mcp_settings.json:

"mcpServers": {
  "mysql": {
    "command": "node",
    "args": [
      "/path/to/zaj_MySQL_MCP/build/index.js"
    ],
    "disabled": false,
    "autoApprove": []
  }
}

Note that database credentials are now configured through the .env file, not through command line arguments.

Building and Running

Clone the repository:

git clone https://github.com/zajTools/zaj-MySQL-MCP.git
cd zaj-MySQL-MCP

Create and configure your .env file:

cp .env.example .env
# Edit .env with your database credentials

Install dependencies:

npm install

Build the server:

npm run build

Run the server:

node build/index.js

Demo and Examples

We've included example materials to help you get started with the MySQL MCP server:

Sample Database: A complete e-commerce database schema with customers, products, orders, and sales data
Example Queries: Pre-written queries demonstrating various capabilities of the MCP server
Usage Scenarios: Examples of how Claude can interact with your MySQL database

To try the demo:

Check out the Demo Guide for step-by-step instructions
Run the Setup SQL Script to create the sample database
Configure the MCP server to connect to the demo database
Start asking Claude questions about your data!

These examples are designed to show the potential of using Claude with MySQL databases, but the MCP server works with any MySQL database you have access to.

License

This MCP server is licensed under the MIT License.
