OCP Viewer MCP Server
An MCP (Model Context Protocol) server that captures screenshots from the OCP CAD Viewer, allowing AI assistants like Cursor to "see" your 3D CAD models.
What it does
When working with CAD tools like CadQuery or Build123d, you can display models in the OCP CAD Viewer using show(). This MCP server lets you ask an AI assistant to capture what's currently displayed, enabling visual feedback and AI-assisted CAD development.
Example workflow:
- You're designing a part in a Jupyter notebook with CadQuery
- You run
show(my_part)to display it in the OCP viewer - You ask the AI: "capture the current view - does this geometry look correct?"
- The AI captures a screenshot and can analyze the 3D model visually
Installation
pip install ocp-viewer-mcp
Requirements:
- Python 3.10+
- OCP CAD Viewer VS Code/Cursor extension
- ocp-vscode Python package (for
show()function)
Configuration
Cursor
Add to your ~/.cursor/mcp.json:
{
"mcpServers": {
"ocp-viewer": {
"command": "python",
"args": ["-m", "ocp_viewer_mcp.server"]
}
}
}
If you're using a virtual environment (recommended), specify the full Python path:
{
"mcpServers": {
"ocp-viewer": {
"command": "/path/to/your/venv/bin/python",
"args": ["-m", "ocp_viewer_mcp.server"]
}
}
}
Claude Desktop
Add to your Claude Desktop config (~/Library/Application Support/Claude/claude_desktop_config.json on macOS):
{
"mcpServers": {
"ocp-viewer": {
"command": "python",
"args": ["-m", "ocp_viewer_mcp.server"]
}
}
}
Usage
- Open your CadQuery/Build123d project in Cursor or VS Code
- Start the OCP CAD Viewer (Cmd+Shift+P → "OCP CAD Viewer: Open Viewer")
- Display a model using
show(your_model)in a notebook or script - Ask the AI to capture the view:
- "Capture the current OCP view"
- "Show me what the model looks like"
- "Take a screenshot of the CAD viewer"
Tool Reference
capture_ocp_screenshot
Captures a screenshot of the OCP CAD Viewer.
| Parameter | Type | Default | Description |
|---|---|---|---|
port | integer | 3939 | The port where OCP viewer is running |
wait_ms | integer | 1000 | Milliseconds to wait for rendering |
Returns: A PNG screenshot as a base64-encoded image.
Troubleshooting
"Could not connect to OCP viewer"
- Make sure the OCP CAD Viewer is open in VS Code/Cursor
- Check that the viewer backend is running (look for "Viewer backend started" in terminal)
- Verify the port (default is 3939)
"ocp_vscode not installed"
The MCP server needs ocp-vscode installed in the same Python environment:
pip install ocp-vscode
Screenshot not capturing
- Make sure a model is displayed (run
show(something)first) - Try increasing
wait_msif the model is complex
Development
# Clone the repo
git clone https://github.com/dmilad/ocp-viewer-mcp.git
cd ocp-viewer-mcp
# Install with Poetry
poetry install
# Run locally
poetry run python -m ocp_viewer_mcp.server
Contributing
Contributions are welcome! Please open an issue first to discuss what you'd like to change.
License
