Unity MCP Server

Unity Asset Store:

1. Visit MCP for Unity on the Asset Store
2. Click Add to My Assets, then import via Window > Package Manager

OpenUPM:

openupm add com.coplaydev.unity-mcp

Key Features

• Natural Language Control — Instruct your LLM to perform Unity tasks
• Powerful Tools — Manage assets, scenes, materials, scripts, and editor functions
• Automation — Automate repetitive Unity workflows
• Extensible — Works with various MCP Clients

Available Tools

manage_asset • manage_editor • manage_gameobject • manage_components • manage_material • manage_prefabs • manage_scene • manage_script • manage_scriptable_object • manage_shader • manage_vfx • manage_texture • batch_execute • find_gameobjects • find_in_file • read_console • refresh_unity • run_tests • get_test_job • execute_menu_item • apply_text_edits • script_apply_edits • validate_script • create_script • delete_script • get_sha

Available Resources

custom_tools • unity_instances • menu_items • get_tests • gameobject • gameobject_components • prefab_api • prefab_info • prefab_hierarchy • editor_state • editor_selection • editor_prefab_stage • project_info • project_tags • project_layers

Performance Tip: Use batch_execute for multiple operations — it's 10-100x faster than individual calls!

If auto-setup doesn't work, add this to your MCP client's config file:

HTTP (default — works with Claude Desktop, Cursor, Windsurf):

{
  "mcpServers": {
    "unityMCP": {
      "url": "http://localhost:8080/mcp"
    }
  }
}

VS Code:

{
  "servers": {
    "unityMCP": {
      "type": "http",
      "url": "http://localhost:8080/mcp"
    }
  }
}

{
  "mcpServers": {
    "unityMCP": {
      "command": "uvx",
      "args": ["--from", "mcpforunityserver", "mcp-for-unity", "--transport", "stdio"]
    }
  }
}

{
  "mcpServers": {
    "unityMCP": {
      "command": "C:/Users/YOUR_USERNAME/AppData/Local/Microsoft/WinGet/Links/uvx.exe",
      "args": ["--from", "mcpforunityserver", "mcp-for-unity", "--transport", "stdio"]
    }
  }
}

MCP for Unity supports multiple Unity Editor instances. To target a specific one:

1. Ask your LLM to check the unity_instances resource
2. Use set_active_instance with the Name@hash (e.g., MyProject@abc123)
3. All subsequent tools route to that instance

For Strict validation that catches undefined namespaces, types, and methods:

1. Install NuGetForUnity
2. Window > NuGet Package Manager → Install Microsoft.CodeAnalysis v5.0
3. Also install SQLitePCLRaw.core and SQLitePCLRaw.bundle_e_sqlite3 v3.0.2
4. Add USE_ROSLYN to Player Settings > Scripting Define Symbols
5. Restart Unity

• Unity Bridge Not Connecting: Check Window > MCP for Unity status, restart Unity
• Server Not Starting: Verify uv --version works, check the terminal for errors
• Client Not Connecting: Ensure the HTTP server is running and the URL matches your config

Detailed setup guides:

• Fix Unity MCP and Cursor, VSCode & Windsurf — uv/Python installation, PATH issues
• Fix Unity MCP and Claude Code — Claude CLI installation
• Common Setup Problems — macOS dyld errors, FAQ

Still stuck? Open an Issue or Join Discord

See README-DEV.md for development setup. For custom tools, see CUSTOM_TOOLS.md.

1. Fork → Create issue → Branch (feature/your-idea) → Make changes → PR

Anonymous, privacy-focused telemetry (no code, no project names, no personal data). Opt out with DISABLE_TELEMETRY=true. See TELEMETRY.md.

@inproceedings{10.1145/3757376.3771417,
author = {Wu, Shutong and Barnett, Justin P.},
title = {MCP-Unity: Protocol-Driven Framework for Interactive 3D Authoring},
year = {2025},
isbn = {9798400721366},
publisher = {Association for Computing Machinery},
address = {New York, NY, USA},
url = {https://doi.org/10.1145/3757376.3771417},
doi = {10.1145/3757376.3771417},
series = {SA Technical Communications '25}
}
