MCP Forensic Toolkit

MCP Forensic Toolkit is a secure, AI-ready local server for digital forensics, built using the Model Context Protocol (MCP). It exposes semantically meaningful tools to analyze logs, verify file integrity, and generate audit-grade forensic reports. Designed for analysts and LLMs alike, it enables automated investigation with precision and safety.

Features

Structured log triage using keyword-based scanning (scan_syslog)
File metadata extraction and SHA-256 hashing (file_metadata)
Recursive integrity scanning with directory hashing (hash_directory)
Correlation engine linking file modifications to log events (correlate_file_and_logs)
Human-readable forensic reporting (generate_forensic_report)
Secure access control via SAFE_BASE and sandboxed environment
Built-in LLM prompts for guided reasoning and forensic tasks

Screenshot

This example demonstrates a successful correlation analysis between a file and system log entries using the generate_forensic_report tool:

Example Correlation Report

Getting Started

Prerequisites

Python 3.10+
Poetry or pip
MCP CLI (pip install modelcontext or follow setup guide)
.env file with SAFE_BASE defined

Installation

Dependencies

Python >= 3.10
Poetry (recommended) or pip for dependency management
Key Python packages installed automatically:
- modelcontext
- fastapi
- uvicorn
- python-dotenv
- typing-extensions

Using Poetry (recommended)

# Clone the repo
git clone https://github.com/axdithyaxo/mcp-forensic-toolkit.git
cd mcp-forensic-toolkit

# Install Poetry if not already installed
curl -sSL https://install.python-poetry.org | python3 -

# Install dependencies and create virtual environment automatically
poetry install

# Activate the Poetry shell
poetry shell

# Create and configure environment variables
cp .env.example .env
# Edit .env and set your SAFE_BASE (e.g. /Users/yourname/Desktop)

Using Python venv and pip (alternative)

# Clone the repo
git clone https://github.com/axdithyaxo/mcp-forensic-toolkit.git
cd mcp-forensic-toolkit

# Create and activate a virtual environment
python -m venv .venv
source .venv/bin/activate  # On Windows use `.venv\Scripts\activate`

# Install dependencies
pip install -r requirements.txt

# Create and configure environment variables
cp .env.example .env
# Edit .env and set your SAFE_BASE (e.g. /Users/yourname/Desktop)

Note for Windows users:

# Use .venv\Scripts\activate to activate the virtual environment instead of source .venv/bin/activate.

Usage

Start the Server

Make sure you have the MCP CLI installed (pip install modelcontext) and dependencies installed (poetry install or pip install -r requirements.txt).

Then start the server:

mcp dev mcp_forensic_toolkit/server.py

---

### Access via MCP Inspector

Use the MCP Inspector or visit:

http://127.0.0.1:6274


You can then:

* Run tools (`scan_syslog`, `file_metadata`, etc.)
* Execute prompts for analysis
* View and inspect structured output

---

## CLI Demo (Optional)

You can run a command-line demo as follows:

```bash
python cli_demo.py ~/Desktop/test_hit.txt correlation

If correlation is found, output includes:

File: /Users/...
Keyword searched in logs: 'correlation'
File modified at: ...
Matching log entries:
  - ...
  - ...
Correlation found: Yes

Otherwise:

Correlation found: No

Example Workflow

Modify or inspect a file within SAFE_BASE.
Run generate_forensic_report or the CLI tool.
Use MCP Inspector or LLM to interpret results.
Example match:

{
  "filename": "/Users/you/Desktop/test_hit.txt",
  "file_modified_time": "2025-06-08T00:26:04.714230",
  "log_hits": [
    "logger: correlation test for test_hit.txt",
    "log run noninteractively, args: ..."
  ],
  "correlation_found": true
}

Environment Variables

Variable	Description
`SAFE_BASE`	Restricts all file operations to this path.

Example .env.example:

SAFE_BASE=/Users/yourname/Desktop

Security Considerations

All tools validate paths against SAFE_BASE
System logs are accessed in a read-only way
Tools gracefully handle permission errors and malformed inputs
CLI interface avoids unsafe globbing or directory traversal

Testing

Run unit tests:

python test_server.py

Or with pytest:

pytest test_server.py -v

Usage Examples

Example: "Investigate File" Prompt in Claude Desktop

Prompt Given

Use the investigate-file prompt to analyze the file at "/Users/username/Desktop/test_hit.txt". Provide the file size, creation and modification times, and SHA-256 hash. Assess if there are any signs of tampering or suspicious characteristics.

Example Response

File Investigation Report

Basic File Information

File Path: /Users/username/Desktop/test_hit.txt
File Size: 9 bytes
Created: June 8, 2025 at 00:26:04.733792 UTC
Modified: June 8, 2025 at 00:26:04.714230 UTC
SHA-256 Hash: 9b7729b1ccfe223076659db07b7f0bb888e139907bb8d7019560166176953fcb

Analysis and Assessment

File Characteristics:

This is a very small file (only 9 bytes), likely containing minimal text content
The file was created and modified almost simultaneously, with the modification timestamp actually preceding the creation timestamp by about 19 milliseconds - this is unusual but can occur due to filesystem timing precision differences

Temporal Analysis:

Creation and modification occurred at 00:26:04 UTC
No specific log entries were found relating to this file’s creation or modification in the system logs
The logs show normal system activity around that time period, primarily power management and Claude desktop application activity

Security Assessment:

There are no apparent signs of tampering or suspicious characteristics:

File Size: The 9-byte size is consistent with a small text file
Timestamps: While the modification time slightly precedes creation time, this is a known filesystem behavior and not indicative of tampering
Hash Integrity: The SHA-256 hash provides a baseline for future integrity verification
System Logs: No suspicious file system activity or security events were detected around the creation time
Location: The file is in a standard user Desktop directory, which is a normal location for user files

Recommendations:

The file appears to be legitimate with no signs of tampering
Store the SHA-256 hash for future integrity verification
Monitor for any unexpected changes by periodically checking its hash

Additional Example Prompts

1. Triage System Logs Prompt

Use the triage-system-logs prompt to search the system logs for the keyword “error”. Summarize the most relevant log entries indicating warnings or security events. Advise if any immediate action is recommended.

2. Correlate Log and File Prompt

Use the correlate-log-and-file prompt to analyze the file “/Users/username/Desktop/test_hit.txt” and search system logs for the keyword “correlation”. Determine if the file modification times align with suspicious log events. Explain the correlation and its forensic implications.

3. Explain Correlation Prompt

Use the explain-correlation prompt with the file “/Users/username/Desktop/test_hit.txt” and keyword “correlation”. Interpret the log hits and file metadata. Provide a concise forensic reasoning summary (under 100 words).

Forensic Analysis Report

A detailed forensic analysis report demonstrating usage and output of the toolkit is available:

Forensic Analysis Report (Markdown)

This report provides an example of the kind of structured output generated by the toolkit’s tools and prompts.

Using with Claude Desktop

To connect MCP Forensic Toolkit with Claude Desktop:

Create a config file, e.g., claude_config.json, with the following content (adjust paths accordingly):

{
  "mcpServers": {
    "MCP Forensic Toolkit": {
      "command": "/path/to/your/venv/bin/mcp",
      "args": ["run", "/path/to/mcp_forensic_toolkit/server.py"]
    }
  }
}

Demo Video

Watch the MCP Forensic Toolkit demo video here:

Demo Video on Google Drive

License

MIT License

Acknowledgments

The Model Context Protocol (MCP) team and community for creating an innovative standard enabling interoperable AI tool integration.
The FastMCP Python SDK developers for providing a robust and user-friendly framework to build MCP servers.
The broader open-source and digital forensics communities for inspiring secure and effective AI-driven investigative tooling.
Projects and initiatives focused on secure AI-agent interfacing and infrastructure automation, which shaped the vision behind this toolkit.
